Reef Factory Dosing Pump x1 CR Pro

Reef Factory Dosing Pump x1 CR Pro dedicated to a calcium reactor or anywhere precise continuous dosing is required

The Dosing Pump CR is a modern peristaltic pump that utilizes a stepper motor. It is designed specifically for a calcium reactor or any situation where precise continuous dosing is essential, without dividing it into doses. For corals and other calcareous organisms to thrive, maintaining specific water parameters is crucial. A calcium reactor serves as an excellent solution, automatically ensuring stable levels of calcium and alkalinity in your marine aquarium.

The Smart Reef application enables remote management of the dosing process. With an intuitive control panel and efficient WiFi communication, you can effortlessly monitor your tank’s status.

Key Features:

• Flow regulation with an accuracy of 0.01 ml/min
• Pump designed for continuous operation
• Pump performance adjustable in the application from 0.1 to 62 ml of liquid per minute
• Quiet and precise operation of proprietary dosing pumps by Reef Factory
• Precise flow regulation independent of pressure changes
• High-precision stepper motor
• High chemical resistance BPT material used for the tubes
• Compact size and modern design
• Easy installation in the sump using a DIN rail

To control your Smart device, simply download the free Smart Reef app available for mobile devices (Android, iOS) or access it through your browser. Pair the device with your Smart Reef account to unlock a variety of smart features.

Smart Functionality:

• User-friendly Smart Reef application available for Android, iOS, or computer (browser support)
• Create and modify a flexible dosing schedule
• Automate dosing based on current levels of monitored parameters
• Specify the pump rotation direction
• Quickly edit dosing and add extra doses outside the schedule
• Dosing in milliliters or percentage (%)
• Clear history of executed liquid dosages
• Manage your aquarium remotely from anywhere, 24/7
• Receive updates on the remaining amount of liquid in the dosing container
• Intuitive and fast calibration process ensures high dosing precision, with push notifications reminding you to repeat it when needed
• Import and export of the dosing schedule

Peristaltic Pumps:

The Dosing Pump CR operates using entirely new proprietary peristaltic pumps developed by the Reef Factory team. These pumps are specifically designed to meet the demands of marine aquarium devices, offering high dosing precision and the longest possible period of trouble-free operation due to their quality components. Plus, they operate very quietly.

Modern Equipment Installation:

To cater to the needs of aquarium enthusiasts, we have enhanced the method of placing equipment within the cabinet. The latest Reef Factory devices incorporate an innovative mounting system based on a DIN rail, providing an extremely convenient and flexible solution to keep your cabinet organized.

Technical Specifications:

Device Dimensions and Weight:

• Width: 6.7 cm / 2.6 in
• Body Depth: 6.7 cm / 2.6 in
• Depth with Head and Bracket: 9.3 cm / 3.7 in
• Height: 6.7 cm / 2.6 in
• Head Dimensions: 4.9×4.9×2.3 cm / 1.9 x 1.9 x 0.91 in

Technical Parameters:

• Dosing Accuracy: +/- 0.01 ml
• Operating Noise: 42 dB
• Durability of the Dosing Head Hose: 1000 h
• Max. Water Tubing Length: 2 m
• WiFi Communication: 2.4 GHz bgn
• Bluetooth Communication: BLE 5.0
• Operating Temperature: 20-30 °C
• Ambient Humidity: 0 to 95% RH

Power Supply Specifications:

• Supply Voltage: 12V 1A via 100-240 V AC 50/60 Hz adapter
• Power Consumption: 0.5-5 W

All devices are CE certified.

Package Contents (CR):

• Device
• User Manual
• 1x RF PRO CR Head
• 2x Additional L Connector – 5.2 mm
• 12V 1.0 A Power Adapter (EU/UK/AU/US)
• DIN Rail Mounting Bracket
• Neodymium Magnet for Device Reset

Smart Reef+:

Reef Factory offers a range of Smart products designed for easy and convenient management of marine aquariums. You can build your own system based on these intelligent devices and control everything through a single application!
